This URL is invalid, sorry. Please use the navigation bar or search to continue.
Scaphandre intends to provide multiple ways to gather power consumption metrics and make understanding tech services footprint possible in many situations. Depending on how you use scaphandre, you may have some restrictions.
To summarize, scaphandre should provide two ways to estimate the power consumption of a service, process or machine. Either by measuring it, using software interfaces that give access to hardware metrics, or by estimating it if measuring is not an option (this is a planned feature, not yet implemented as those lines are written, in december 2020).
In scaphandre, the code responsible to collect the power consumption data before any further processing is grouped in components called sensors. If you want more details about scaphandre structure, here are the explanations.
On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn't work in all contexts.
On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR's enables you to do (almost) the same.
On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn’t work in all contexts.
On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR’s enables you to do (almost) the same.
Sensors including "RAPL" in their name rely on RAPL.
The pts and pln feature flags ("Intel Package Thermal Status" and "Intel Power Limit Notification" respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches :
pts
pln
egrep "(pts|pln)" /proc/cpuinfo +Sensors including “RAPL” in their name rely on RAPL. +The pts and pln feature flags (“Intel Package Thermal Status” and “Intel Power Limit Notification” respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : +egrep "(pts|pln)" /proc/cpuinfo
Sensors including “RAPL” in their name rely on RAPL.
The pts and pln feature flags (“Intel Package Thermal Status” and “Intel Power Limit Notification” respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches :
egrep "(pts|pln)" /proc/cpuinfo
If you are reading this, you may be to contribute. Just for that, a big thank you ! 👏
Place the resulting documentation folder next to scaphandre's folder. Then run the build:
Place the resulting documentation folder next to scaphandre’s folder. Then run the build:
cd scaphandre && mdbook build
You should then have the result in scaphandre-documentation/docs. Commit, push and propose a PR to publish the changes.
scaphandre-documentation/docs
There are several ways scaphandre can interact with containers.
You may run scaphandre in a container, to not have to manage the dependencies, then measure the power consumption of the bare metal host. This is described in the quickstart tutorial. Note that you need to expose /sys/class/powercap and /proc as volumes in the container to allow scaphandre to get the relevant metrics from the bare metal host.
/sys/class/powercap
/proc
Scaphandre may help you measure the power consumption of containers running on a given host. You can already get to that goal using the tips provided in the howto section called "Get process level power consumption". It may still require some tweaking and inventiveness from you in making the approriate queries to your favorite TSDB. This should be made easier by the upcoming scaphandre features.
Scaphandre may help you measure the power consumption of containers running on a given host. You can already get to that goal using the tips provided in the howto section called “Get process level power consumption”. It may still require some tweaking and inventiveness from you in making the approriate queries to your favorite TSDB. This should be made easier by the upcoming scaphandre features.
Another use case scenario is measuring the power consumption of a container orchestrator (like kubernetes), its nodes and the containers and applications running on it. Scaphandre can be installed on Kubernetes via the Helm chart and there is a tutorial for installing it along with Prometheus and Grafana to view the metrics.
As described here, scaphandre provides several ways (sensors) to collect the power consumption metrics. Depending on your use case a sensor should be more suitable than the other. Each of them comes with strengths and weaknesses. This is basically always a tradeoff between precision and simplicity. This is especially true if you run a container-based workloads on public cloud instances. We are working to provide a solution for that as well.
This is true starting from Scaphandre >= 1.0.
In addition to those metrics, you might want to build, on your time series database, the sum of process_ metrics to have a view of the weight of all processes on the host power. Using Prometheus, it would look like: sum(scaph_process_power_consumption_microwatts{hostname="$hostname"}) / 1000000, to get it in Watts.
sum(scaph_process_power_consumption_microwatts{hostname="$hostname"}) / 1000000
Let's explain the relationship between those metrics, and what you could expect.
Let’s explain the relationship between those metrics, and what you could expect.
host_power metric will return :
host_power
Briefly explained (see RAPL domains for detailled explanations), PSYS covers most components on the machine ("all components connected to the SoC / motherboard" according to most documentations), so we return this wider ranged metric when available. If not we use a combination of PKG domain, that includes CPU and integrated GPU power, and DRAM domain, that includes memory power. The first options gives higher figures than the second, for now.
Suming the power of all processes, if the machine is mostly IDLE, you'll get a tiny percentage of the host machine, most likely. The difference between host power and the sum of processes power can be accounted as "power due to IDLE activity", in other words the power your machine demands for "doing nothing". The higher this difference on a long period of time (better seen as a graph), the higher chance that there is room for improvement in moving the workloads to another machine and shut the current machine down (and make it available for another project or to another organization to prevent from buying a new machine).
Briefly explained (see RAPL domains for detailled explanations), PSYS covers most components on the machine (“all components connected to the SoC / motherboard” according to most documentations), so we return this wider ranged metric when available. If not we use a combination of PKG domain, that includes CPU and integrated GPU power, and DRAM domain, that includes memory power. The first options gives higher figures than the second, for now.
Suming the power of all processes, if the machine is mostly IDLE, you’ll get a tiny percentage of the host machine, most likely. The difference between host power and the sum of processes power can be accounted as “power due to IDLE activity”, in other words the power your machine demands for “doing nothing”. The higher this difference on a long period of time (better seen as a graph), the higher chance that there is room for improvement in moving the workloads to another machine and shut the current machine down (and make it available for another project or to another organization to prevent from buying a new machine).
Warning: that being said, the way per-process power is computed is still biased and shall be improved in the following versions of Scaphandre. For now, the main key for allocation is CPU time. As host level power metrics include power usage of more and more components on the machine (work in progress) this allocation key will be more and more inaccurate. Future versions of this allocation model should include keys regarding the activity of other components than CPU. Enabling a better set of allocation keys for per-process power is part of the roadmap.
Scaphandre is a tool that makes it possible to see the power being used by a single process on a computer.
This sounds like a simple thing thing to be able to do, but in practice a number of details can make this more complex.
So having a good mental model of how it works will make it easier to understand when and how to use Scaphandre. Let's start with a simplified mental model below, before moving on to multiple processors or virtual machines - but once you understand the key ideas outlined below, it's easier to see how they can be applied to thinking about tracking power on virtual machines, or when multiple processors are available.
This sounds like a simple thing to be able to do, but in practice a number of details can make this more complex.
So having a good mental model of how it works will make it easier to understand when and how to use Scaphandre. Let’s start with a simplified mental model below, before moving on to multiple processors or virtual machines - but once you understand the key ideas outlined below, it’s easier to see how they can be applied to thinking about tracking power on virtual machines, or when multiple processors are available.
When we first think about how much energy a single process running in a computer might use, we might start with a mental model that looks like the figure below, with large, uninterrupted chunks of compute time allocated to each process.
This is easy to understand, and it matches how we might be billed for a share of a larger machine when paying for cloud services.
However, if the reality was exactly like this diagram, our computers would only ever be able to do one thing at a time. It's more accurate and helpful to think of computers working on lots of different jobs at the same time - they work on one job for short interval of time, then another, and another and so one. You'll often see these small intervals of time referred to as jiffies.
In a given amount of time, some jobs that are prioritized or more resource intensive will use more jiffies than others. Fortunately, each job keeps a running total of the total jiffies allocated to it, so if we know how many jiffies have been used in total, it can give us an idea how much of a machine's resources are being used by a given process.
However, if the reality was exactly like this diagram, our computers would only ever be able to do one thing at a time. It’s more accurate and helpful to think of computers working on lots of different jobs at the same time - they work on one job for short interval of time, then another, and another and so one. You’ll often see these small intervals of time referred to as jiffies.
In a given amount of time, some jobs that are prioritized or more resource intensive will use more jiffies than others. Fortunately, each job keeps a running total of the total jiffies allocated to it, so if we know how many jiffies have been used in total, it can give us an idea how much of a machine’s resources are being used by a given process.
It's possible without Scaphandre to understand how large a share of a machines' resources are being used by a given process.
This is useful, by itself, but if we want to understand how much power is used per process, not just the share of the machine's resources, we need to know how much power is being used by the machine in absolute terms.
To do this, we need a sensor of some kind to track power usage by the machine itself. Some servers have these, like with Intel's RAPL sensors, which we cover this in more detail later on. This makes it possible to understand how much power is being used by CPUs, GPUs and so on, in terms of watts, or, if we are looking at just a single process, various fractions of a watt.
To understand the power used by a single process we combine both of these ideas. We count the jiffies used by our job when it's being worked on, and for each jiffy, we check how much power is being drawn at those moments in time.
It’s possible without Scaphandre to understand how large a share of a machines’ resources are being used by a given process.
This is useful, by itself, but if we want to understand how much power is used per process, not just the share of the machine’s resources, we need to know how much power is being used by the machine in absolute terms.
To do this, we need a sensor of some kind to track power usage by the machine itself. Some servers have these, like with Intel’s RAPL sensors, which we cover in more detail later on. This makes it possible to understand how much power is being used by CPUs, GPUs and so on, in terms of watts, or, if we are looking at just a single process, various fractions of a watt.
To understand the power used by a single process we combine both of these ideas. We count the jiffies used by our job when it’s being worked on, and for each jiffy, we check how much power is being drawn at those moments in time.
Finally, when we group together all the power readings for all our jiffies over a given time period, we can arrive at a usable figure for how much power has been used, in terms of watt hours.
Once we have a figure in terms of watt hours, there are various ways we can convert this to environmental impact. A common way is to use an emission factor for the electricity used, to turn the power consumption data into an estimate of associated carbon emissions.
While the reality is again more complicated than the diagram below, the same ideas broadly apply when you introduce multiple processors too.
If you are able to read from sensors that can share how much power is being used by the various processors at work, and know how much of the time is being allocated to our processes during those moments, you can get a good idea of what these figures are, at a per-process level.
Things get a bit more complicated with virtualised environments, because in many cases, virtual machines only have a partial view of the system they are part of, and frequently do not have access to any power usage figures from the host physical machine.
However, if a guest virtual machine or guest container does have access to readings provided by the host physical machine, it is possible to work out the same kinds of per-process power figures. Scaphandre supports exposing these kinds of power readings to virtual machines and containers, which means, if you are running on infrastructure that is running scaphandre and exposing these readings, you can see these figures for the energy used by your own processes.
As you can see with the prometheus exporter reference, scaphandre exporters can provide process level power consumption metrics. This section will explain how it is done and how it may be improved in the future.
We'll talk here about the case where scaphandre is able to effectively measure the power consumption of the host (see compatibility section for more on sensors and their prerequisites) and specifically about the PowercapRAPL sensor.
Let's clarify what's happening when you collect metrics with scaphandre and the RAPL sensor. -RAPL stands for Running Average Power Limit. It's a technology embedded in most Intel and AMD x86 CPUs produced after 2012.
We’ll talk here about the case where scaphandre is able to effectively measure the power consumption of the host (see compatibility section for more on sensors and their prerequisites) and specifically about the PowercapRAPL sensor.
Let’s clarify what’s happening when you collect metrics with scaphandre and the RAPL sensor. +RAPL stands for Running Average Power Limit. It’s a technology embedded in most Intel and AMD x86 CPUs produced after 2012.
Thanks to this technology it is possible to get the total energy consumption of the CPU, of the consumption per CPU socket, plus in some cases, the consumption of the DRAM controller. In most cases it represents the vast majority of the energy consumption of the machine (except when running GPU intensive workloads, for example).
Further improvements shall be made in scaphandre to fully measure the consumption when GPU are involved (or a lot of hard drives on the same host...).
Further improvements shall be made in scaphandre to fully measure the consumption when GPU are involved (or a lot of hard drives on the same host…).
Between scaphandre and this data is the powercap kernel module that writes the energy consumption to files. Scaphandre reads those files, stores the data in buffers and then allows for more processing through the exporters.
The PowercapRAPL sensor does actually more than just collecting those energy consumption metrics (and converting them to power consumption metrics).
Every time the exporter asks for a measurement (either periodically like in the Stdout exporter, or every time a request comes as would be the case for the Prometheus exporter) the sensor reads the values of the energy counters from powercap. It then stores those values, and does the same for the CPU usage statistics of the CPU (the one you can see in /proc/stats) and for each running process on the machine at that time (see /proc/PID/stats).
/proc/stats
/proc/PID/stats
With this data it is possible to compute the ratio of CPU time actively spent for a given PID on the CPU time actively spent doing something. With this ratio we can then get the subset of power consumption that is related to that PID on a given timeframe (between two measurement requests).
Services and programs are often not running on only one PID. It's needed to aggregate the consumption of all related PIDs to know what this service is actually consuming.
To do that, in the current state of scaphandre development, you can use the Prometheus exporter, and then use Prometheus and its query language capabilities. You'll find examples looking at the graphs and queries here. In a near future, more advanced features may be implemented in scaphandre to allow such classification even if you don't have access to a proper Time Series database (TSDB).
Services and programs are often not running on only one PID. It’s needed to aggregate the consumption of all related PIDs to know what this service is actually consuming.
To do that, in the current state of scaphandre development, you can use the Prometheus exporter, and then use Prometheus and its query language capabilities. You’ll find examples looking at the graphs and queries here. In a near future, more advanced features may be implemented in scaphandre to allow such classification even if you don’t have access to a proper Time Series database (TSDB).
Scaphandre is designed to be extensible. As it performs basically two tasks: collecting/pre-computing the power consumption metrics and publishing it, it is composed of two main components: a sensor and an exporter. Each can be implemented in different ways to match a certain use case. When you run scaphandre from the command line, -s allows you to choose the sensor you want to use, and the next subcommand is the name of the exporter.
-s
The PowercapRAPL for instance, gets and transforms metrics coming from the powercap Linux kernel module, that serves as an interface to get the data from the RAPL feature of x86 CPUs. Because this feature is only accessible when you are running on a bare metal machine, this sensor will not work in a virtual machine, except if you first run scaphandre on the hypervisor and make the VM metrics available, with the qemu exporter, to scaphandre running inside the virtual machine.
When you don't have access to the hypervisor/bare-metal machine (ie. when you run on public cloud instances and your provider doesn't run scaphandre) you still have the option to estimate the power consumption, based on both the ressources (cpu/gpu/ram/io...) consumed by the virtual machine at a given time, and the characteristics of the underlying hardware. This is the way we are designing the future estimation-based sensor, to match that use case.
Looking at the code, you'll find that the interface between metrics and the exporters is in fact the Topology object. This is intended to be asked by the exporter through the get_topology method of the sensor.
When you don’t have access to the hypervisor/bare-metal machine (ie. when you run on public cloud instances and your provider doesn’t run scaphandre) you still have the option to estimate the power consumption, based on both the ressources (cpu/gpu/ram/io…) consumed by the virtual machine at a given time, and the characteristics of the underlying hardware. This is the way we are designing the future estimation-based sensor, to match that use case.
Looking at the code, you’ll find that the interface between metrics and the exporters is in fact the Topology object. This is intended to be asked by the exporter through the get_topology method of the sensor.
An exporter is expected to:
The Stdout exporter exposes the metrics on the standard output (in your terminal). The prometheus exporter exposes the metrics on an HTTP endpoint, to be scraped by a prometheus instance. An exporter should be created for each monitoring scenario (do you want to feed your favorite monitoring/data analysis tool with scaphandre metrics ? feel free to open a PR to create a new exporter !).
As introduced in the sensors section, the Qemu exporter, is very specific. It is only intended to collect metrics related to running virtual machines on a Qemu/KVM hypervisor. Those metrics can then be made available to each virtual machine and their own scaphandre instance, running the PowercapRAPL sensor (with the --vm flag on). The qemu exporter puts VM's metrics in files the same way the powercap kernel module does it. It mimics this behavior, so the sensor can act the same way it would on a bare metal machine.
--vm
As introduced in the sensors section, the Qemu exporter, is very specific. It is only intended to collect metrics related to running virtual machines on a Qemu/KVM hypervisor. Those metrics can then be made available to each virtual machine and their own scaphandre instance, running the PowercapRAPL sensor (with the --vm flag on). The qemu exporter puts VM’s metrics in files the same way the powercap kernel module does it. It mimics this behavior, so the sensor can act the same way it would on a bare metal machine.
RAPL stands for "Running Average Power Limit", it is a feature on Intel/AMD x86 CPU's (manufactured after 2012) that allows to set limits on power used by the CPU and other components. This feature also allows to just get "measurements" (mind the double quotes, as at least part of the numbers RAPL gives are coming from estimations/modeling) of components power usage.
It is composed of "domains", that, in 2023, may include:
RAPL stands for “Running Average Power Limit”, it is a feature on Intel/AMD x86 CPU’s (manufactured after 2012) that allows to set limits on power used by the CPU and other components. This feature also allows to just get “measurements” (mind the double quotes, as at least part of the numbers RAPL gives are coming from estimations/modeling) of components power usage.
It is composed of “domains”, that, in 2023, may include:
RAPL documentation from Intel doesn't necessarily give very precise informations about how RAPL behaves depending on the platform, or about what is included in the calculation. Actively looking for other experimentations/feedbacks/documentations is needed. You might find some informations gathered here: awesome-energy. If you have more or more precise informations and are willing to contribute, don't hesitate to open a PR to dev branch on scaphandre's repository (targeting docs_src folder) and/or the awesome-energy repository.
RAPL documentation from Intel doesn’t necessarily give very precise informations about how RAPL behaves depending on the platform, or about what is included in the calculation. Actively looking for other experimentations/feedbacks/documentations is needed. You might find some informations gathered here: awesome-energy. If you have more or more precise informations and are willing to contribute, don’t hesitate to open a PR to dev branch on scaphandre’s repository (targeting docs_src folder) and/or the awesome-energy repository.
If you want to know if RAPL is supported by your CPU, please have a look to the end of the Compatibility section.
Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ?
Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ?
You need basically 3 components for that:
We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana.
We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana.
How to get metrics per process as you may see here ?
The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time.
scaph_process_power_consumption_microwatts
This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid.
instance
exe
job
pid
If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource:
scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - + Those labels are explained in much more detail here.
scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000
Here we assume that scaphandre/the prometheus exporter is running on port number 8080.
8080
Here is how it looks, creating a panel in grafana:
Those labels are explained in much more detail here.
You can download it and install it just providing the right URL to dnf :
dnf install -y URL
Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file :
Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file :
vi /etc/scaphandre/prometheuspush
Default options look like :
SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -177,7 +210,7 @@ - + - - + + @@ -205,17 +238,38 @@ - + - - + +
SCAPHANDRE_ARGS="prometheus-push -H localhost -S http"
Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options :
/usr/bin/scaphandre-prometheuspush --help
A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like :
SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -177,7 +210,7 @@ - + - - + + @@ -205,17 +238,38 @@ - + - - + +
SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30"
Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot :
systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -177,7 +210,7 @@ - + - - + + @@ -205,17 +238,38 @@ - + - - + +
A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics.
A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics.
Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine).
This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors.
This is working on Qemu/KVM hypervisors only.
The idea is to run the agent on the hypervisor, with the qemu exporter:
scaphandre qemu
More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :)
More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :)
For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint:
mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m
Save and (re)start the virtual machine.
If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section.
<domain>
If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section.
<memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -182,18 +215,18 @@ How to scaphandre --vm prometheus Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier.
scaphandre --vm prometheus
Please refer to the qemu exporter reference for more details.
Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier.
Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier.
Welcome on Scaphandre documentation.
Scaphandre is a monitoring agent, dedicated to energy consumption metrics. Its purpose is to help measuring and thus understanding tech services energy consumption patterns. This is key, in our opinion, to enable the tech industry to shift towards more sustainability. 💚
If at this point you think "why bother ?", or if you want more details about this project's motivations, please have a look at the why section.
If at this point you think “why bother ?”, or if you want more details about this project’s motivations, please have a look at the why section.
If not and you want to proceed, just directly jump to the tutorials section.
If you need more in-depth, use-case oriented instructions, the how-to guides are here for you.
Explanations is about theoretical concepts behind scaphandre and the reasons for the technical choices that have been made so far.
If you are already using, hacking or exploring scaphandre and need precise informations about one of its components, go to the references section. (The code documentation itself is here).
To install Scaphandre, depending on your platform, see:
If you want to contribute or just play with the code and need to compile Scaphandre, see :
Depending on your kernel version, you could need to modprobe the module intel_rapl or intel_rapl_common first:
modprobe intel_rapl_common # or intel_rapl for kernels < 5
To quickly run scaphandre in your terminal you may use docker:
docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15 +docker run --privileged -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15 -Or if you downloaded or built a binary, you'd run: +To run scaphandre you need to run the contaner in privileged mode since it is needed to access /proc files. +Or if you downloaded or built a binary, you’d run: scaphandre stdout -t 15 -Running scaphandre on Fedora / CentOS Stream / RHEL (or any distribution using SELinux) with podman -Running scaphandre with podman on a distribution using SELinux may fail because of access denied to /proc files. -To make it work you should run scaphandre in privileged mode : -podman run --privileged ... - -You'll find explanation of this requirement here : #106. Output -Here we are using the stdout exporter to print current power consumption usage in the terminal during 15 seconds. +Here we are using the stdout exporter to print current power consumption usage in the terminal during 15 seconds. You should get an output like: Host: 9.391334 W Core Uncore DRAM Socket0 9.392 W 1.497082 W Top 5 consumers: Power PID Exe -4.808363 W 642 "/usr/sbin/dockerd" -4.808363 W 703 "/usr/bin/docker-containerd" -4.808363 W 1028 "/usr/local/bin/redis-server" -0 W 1 "/usr/lib/systemd/systemd" -0 W 2 "" +4.808363 W 642 "/usr/sbin/dockerd" +4.808363 W 703 "/usr/bin/docker-containerd" +4.808363 W 1028 "/usr/local/bin/redis-server" +0 W 1 "/usr/lib/systemd/systemd" +0 W 2 "" ------------------------------------------------------------ -Let's briefly describe what you see here. First Line is the power consumption of the machine (between the two last measurements). +Let’s briefly describe what you see here. First Line is the power consumption of the machine (between the two last measurements). Second line is the power consumption of the first CPU socket plus the detail by RAPL Domain. -If you have more than one CPU Socket, you'll have multiple SocketX lines. +If you have more than one CPU Socket, you’ll have multiple SocketX lines. Then you have the 5 processes consuming the most power during the last two measurements. -If you don't get this output and get an error, jump to the Troubleshooting section of the documentation. +If you don’t get this output and get an error, jump to the Troubleshooting section of the documentation. Going further -At that point, you're ready to use scaphandre. The Stdout exporter is very basic and other exporters should allow you to use and send those metrics the way you like. -The prometheus exporter, for example, allows you to expose power consumption metrics as an HTTP endpoint that can be scrapped by a prometheus instance: -docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -p 8080:8080 -ti hubblo/scaphandre prometheus +At that point, you’re ready to use scaphandre. The Stdout exporter is very basic and other exporters should allow you to use and send those metrics the way you like. +The prometheus exporter, for example, allows you to expose power consumption metrics as an HTTP endpoint that can be scrapped by a prometheus instance: +docker run --privileged -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -p 8080:8080 -ti hubblo/scaphandre prometheus Here is the same command with a simple binary: scaphandre prometheus @@ -208,21 +237,35 @@ Going further curl -s http://localhost:8080/metrics Here you can see examples of graphs you can get thanks to scaphandre, the prometheus exporter, prometheus and grafana. -Installation (GNU/Linux) + +Installation (GNU/Linux) Depending on your kernel version, you could need to modprobe the module intel_rapl or intel_rapl_common before running scaphandre: modprobe intel_rapl_common # or intel_rapl for kernels < 5 +Docker To quickly run scaphandre in your terminal you may use docker: docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15 -Or if you downloaded or built a binary, you'd run: +Debian/Ubuntu +Since Debian Sid, Scaphandre is available as an official package, try: +sudo apt install scaphandre + +If not (yet) in your official packages repositories, on Debian or Ubuntu, you can directly use the available .deb package for Debian Bullseye or the package for Debian Bookworm. +# For Debian Bookworm +VERSION="1.0.1" ARCH="amd64" DIST="deb12" && \ +wget https://github.com/hubblo-org/scaphandre/releases/download/v${VERSION}/scaphandre_v${VERSION}-${DIST}_${ARCH}.deb && \ +dpkg -i scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb && \ +rm scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb + +Run the binary +Once you downloaded or built a binary, you’d run: scaphandre stdout -t 15 Here are some other ways to install scaphandre depending on your context: -quickly try the project with docker-compose/docker stack -run scaphandre on kubernetes -run scaphandre on RHEL, with prometheus-push mode +quickly try the project with docker-compose/docker stack +run scaphandre on kubernetes +run scaphandre on RHEL, with prometheus-push mode Kudos to contributors who work on system packages, please have a try and/or contribute to: @@ -234,22 +277,23 @@ Going further install scaphandre as a proper systemd service scaphandre in your favorite GNU/Linux distribution (need help from packaging gurus !) scaphandre on MacOSX -and more... +and more… -Install Scaphandre on Windows + +Install Scaphandre on Windows !! Warning: Windows version of Scaphandre is still in early stage. !! Using the installer -Download the package and install it as an administrator. +Download the latest exe installer from the release page and install it as an administrator. Configuring a Windows service to run Scaphandre in the background For example, to run the prometheus-push exporter in the background and target the Prometheus Push Gateway server with ip address 198.51.100.5 using HTTPS on port 443 and a step to send metrics of 45s, without checking the certificate of the push gateway (remove that option if you have a properly signed TLS certificate): -sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto +sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto Ensure the service is started in Services.msc, start it by right clicking on it, then Start, otherwise. -To delete the service, you can do it in Services.msc, or: +To delete the service, you can do it in Services.msc, or: sc.exe delete Scaphandre Using an installer including a development version of the driver -If you are running a development version of the installer (which probably means a development version of the driver), you'll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. +If you are running a development version of the installer (which probably means a development version of the driver), you’ll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. bcdedit.exe -set TESTSIGNING ON bcdedit.exe -set nointegritychecks on @@ -261,15 +305,16 @@ Troubleshooti An error such as scaphandre::sensors::msr_rapl: Failed to open device : HANDLE(-1) -means that the driver is not properly setup. Check it's state by running: +means that the driver is not properly setup. Check it’s state by running: driverquery /v | findstr capha If there is not item returned, the installation of the driver encountered an issue. If the service is STOPPED, there is also something wrong. Compilation -If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows -Run a complete stack with docker-compose -If you'd like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. +If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows + +Run a complete stack with docker-compose +If you’d like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. Once you have cloned the repository, just move to the docker-compose folder and run the stack: cd docker-compose docker-compose up -d @@ -281,7 +326,8 @@ Compilation To remove the stack just run this command in the same folder: docker-compose down -Compile scaphandre from source (GNU/Linux) + +Compile scaphandre from source (GNU/Linux) We recommand using this version of the rust toolchain or later: cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml Get the Grafana web UI password which is randomly generated. -kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
docker run --privileged -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15
Or if you downloaded or built a binary, you'd run:
To run scaphandre you need to run the contaner in privileged mode since it is needed to access /proc files.
Or if you downloaded or built a binary, you’d run:
scaphandre stdout -t 15
Running scaphandre with podman on a distribution using SELinux may fail because of access denied to /proc files.
To make it work you should run scaphandre in privileged mode :
podman run --privileged ... -
You'll find explanation of this requirement here : #106.
Here we are using the stdout exporter to print current power consumption usage in the terminal during 15 seconds.
You should get an output like:
Host: 9.391334 W Core Uncore DRAM Socket0 9.392 W 1.497082 W Top 5 consumers: Power PID Exe -4.808363 W 642 "/usr/sbin/dockerd" -4.808363 W 703 "/usr/bin/docker-containerd" -4.808363 W 1028 "/usr/local/bin/redis-server" -0 W 1 "/usr/lib/systemd/systemd" -0 W 2 "" +4.808363 W 642 "/usr/sbin/dockerd" +4.808363 W 703 "/usr/bin/docker-containerd" +4.808363 W 1028 "/usr/local/bin/redis-server" +0 W 1 "/usr/lib/systemd/systemd" +0 W 2 "" ------------------------------------------------------------
Let's briefly describe what you see here. First Line is the power consumption of the machine (between the two last measurements). +
Let’s briefly describe what you see here. First Line is the power consumption of the machine (between the two last measurements). Second line is the power consumption of the first CPU socket plus the detail by RAPL Domain. -If you have more than one CPU Socket, you'll have multiple SocketX lines. +If you have more than one CPU Socket, you’ll have multiple SocketX lines. Then you have the 5 processes consuming the most power during the last two measurements.
If you don't get this output and get an error, jump to the Troubleshooting section of the documentation.
If you don’t get this output and get an error, jump to the Troubleshooting section of the documentation.
At that point, you're ready to use scaphandre. The Stdout exporter is very basic and other exporters should allow you to use and send those metrics the way you like.
The prometheus exporter, for example, allows you to expose power consumption metrics as an HTTP endpoint that can be scrapped by a prometheus instance:
docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -p 8080:8080 -ti hubblo/scaphandre prometheus +At that point, you’re ready to use scaphandre. The Stdout exporter is very basic and other exporters should allow you to use and send those metrics the way you like. +The prometheus exporter, for example, allows you to expose power consumption metrics as an HTTP endpoint that can be scrapped by a prometheus instance: +docker run --privileged -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -p 8080:8080 -ti hubblo/scaphandre prometheus Here is the same command with a simple binary: scaphandre prometheus @@ -208,21 +237,35 @@ Going further curl -s http://localhost:8080/metrics Here you can see examples of graphs you can get thanks to scaphandre, the prometheus exporter, prometheus and grafana. -Installation (GNU/Linux) + +Installation (GNU/Linux) Depending on your kernel version, you could need to modprobe the module intel_rapl or intel_rapl_common before running scaphandre: modprobe intel_rapl_common # or intel_rapl for kernels < 5 +Docker To quickly run scaphandre in your terminal you may use docker: docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15 -Or if you downloaded or built a binary, you'd run: +Debian/Ubuntu +Since Debian Sid, Scaphandre is available as an official package, try: +sudo apt install scaphandre + +If not (yet) in your official packages repositories, on Debian or Ubuntu, you can directly use the available .deb package for Debian Bullseye or the package for Debian Bookworm. +# For Debian Bookworm +VERSION="1.0.1" ARCH="amd64" DIST="deb12" && \ +wget https://github.com/hubblo-org/scaphandre/releases/download/v${VERSION}/scaphandre_v${VERSION}-${DIST}_${ARCH}.deb && \ +dpkg -i scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb && \ +rm scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb + +Run the binary +Once you downloaded or built a binary, you’d run: scaphandre stdout -t 15 Here are some other ways to install scaphandre depending on your context: -quickly try the project with docker-compose/docker stack -run scaphandre on kubernetes -run scaphandre on RHEL, with prometheus-push mode +quickly try the project with docker-compose/docker stack +run scaphandre on kubernetes +run scaphandre on RHEL, with prometheus-push mode Kudos to contributors who work on system packages, please have a try and/or contribute to: @@ -234,22 +277,23 @@ Going further install scaphandre as a proper systemd service scaphandre in your favorite GNU/Linux distribution (need help from packaging gurus !) scaphandre on MacOSX -and more... +and more… -Install Scaphandre on Windows + +Install Scaphandre on Windows !! Warning: Windows version of Scaphandre is still in early stage. !! Using the installer -Download the package and install it as an administrator. +Download the latest exe installer from the release page and install it as an administrator. Configuring a Windows service to run Scaphandre in the background For example, to run the prometheus-push exporter in the background and target the Prometheus Push Gateway server with ip address 198.51.100.5 using HTTPS on port 443 and a step to send metrics of 45s, without checking the certificate of the push gateway (remove that option if you have a properly signed TLS certificate): -sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto +sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto Ensure the service is started in Services.msc, start it by right clicking on it, then Start, otherwise. -To delete the service, you can do it in Services.msc, or: +To delete the service, you can do it in Services.msc, or: sc.exe delete Scaphandre Using an installer including a development version of the driver -If you are running a development version of the installer (which probably means a development version of the driver), you'll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. +If you are running a development version of the installer (which probably means a development version of the driver), you’ll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. bcdedit.exe -set TESTSIGNING ON bcdedit.exe -set nointegritychecks on @@ -261,15 +305,16 @@ Troubleshooti An error such as scaphandre::sensors::msr_rapl: Failed to open device : HANDLE(-1) -means that the driver is not properly setup. Check it's state by running: +means that the driver is not properly setup. Check it’s state by running: driverquery /v | findstr capha If there is not item returned, the installation of the driver encountered an issue. If the service is STOPPED, there is also something wrong. Compilation -If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows -Run a complete stack with docker-compose -If you'd like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. +If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows + +Run a complete stack with docker-compose +If you’d like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. Once you have cloned the repository, just move to the docker-compose folder and run the stack: cd docker-compose docker-compose up -d @@ -281,7 +326,8 @@ Compilation To remove the stack just run this command in the same folder: docker-compose down -Compile scaphandre from source (GNU/Linux) + +Compile scaphandre from source (GNU/Linux) We recommand using this version of the rust toolchain or later: cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml Get the Grafana web UI password which is randomly generated. -kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
At that point, you’re ready to use scaphandre. The Stdout exporter is very basic and other exporters should allow you to use and send those metrics the way you like.
docker run --privileged -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -p 8080:8080 -ti hubblo/scaphandre prometheus
Here is the same command with a simple binary:
scaphandre prometheus @@ -208,21 +237,35 @@ Going further curl -s http://localhost:8080/metrics Here you can see examples of graphs you can get thanks to scaphandre, the prometheus exporter, prometheus and grafana. -Installation (GNU/Linux) + +Installation (GNU/Linux) Depending on your kernel version, you could need to modprobe the module intel_rapl or intel_rapl_common before running scaphandre: modprobe intel_rapl_common # or intel_rapl for kernels < 5 +Docker To quickly run scaphandre in your terminal you may use docker: docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15 -Or if you downloaded or built a binary, you'd run: +Debian/Ubuntu +Since Debian Sid, Scaphandre is available as an official package, try: +sudo apt install scaphandre + +If not (yet) in your official packages repositories, on Debian or Ubuntu, you can directly use the available .deb package for Debian Bullseye or the package for Debian Bookworm. +# For Debian Bookworm +VERSION="1.0.1" ARCH="amd64" DIST="deb12" && \ +wget https://github.com/hubblo-org/scaphandre/releases/download/v${VERSION}/scaphandre_v${VERSION}-${DIST}_${ARCH}.deb && \ +dpkg -i scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb && \ +rm scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb + +Run the binary +Once you downloaded or built a binary, you’d run: scaphandre stdout -t 15 Here are some other ways to install scaphandre depending on your context: -quickly try the project with docker-compose/docker stack -run scaphandre on kubernetes -run scaphandre on RHEL, with prometheus-push mode +quickly try the project with docker-compose/docker stack +run scaphandre on kubernetes +run scaphandre on RHEL, with prometheus-push mode Kudos to contributors who work on system packages, please have a try and/or contribute to: @@ -234,22 +277,23 @@ Going further install scaphandre as a proper systemd service scaphandre in your favorite GNU/Linux distribution (need help from packaging gurus !) scaphandre on MacOSX -and more... +and more… -Install Scaphandre on Windows + +Install Scaphandre on Windows !! Warning: Windows version of Scaphandre is still in early stage. !! Using the installer -Download the package and install it as an administrator. +Download the latest exe installer from the release page and install it as an administrator. Configuring a Windows service to run Scaphandre in the background For example, to run the prometheus-push exporter in the background and target the Prometheus Push Gateway server with ip address 198.51.100.5 using HTTPS on port 443 and a step to send metrics of 45s, without checking the certificate of the push gateway (remove that option if you have a properly signed TLS certificate): -sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto +sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto Ensure the service is started in Services.msc, start it by right clicking on it, then Start, otherwise. -To delete the service, you can do it in Services.msc, or: +To delete the service, you can do it in Services.msc, or: sc.exe delete Scaphandre Using an installer including a development version of the driver -If you are running a development version of the installer (which probably means a development version of the driver), you'll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. +If you are running a development version of the installer (which probably means a development version of the driver), you’ll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. bcdedit.exe -set TESTSIGNING ON bcdedit.exe -set nointegritychecks on @@ -261,15 +305,16 @@ Troubleshooti An error such as scaphandre::sensors::msr_rapl: Failed to open device : HANDLE(-1) -means that the driver is not properly setup. Check it's state by running: +means that the driver is not properly setup. Check it’s state by running: driverquery /v | findstr capha If there is not item returned, the installation of the driver encountered an issue. If the service is STOPPED, there is also something wrong. Compilation -If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows -Run a complete stack with docker-compose -If you'd like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. +If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows + +Run a complete stack with docker-compose +If you’d like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. Once you have cloned the repository, just move to the docker-compose folder and run the stack: cd docker-compose docker-compose up -d @@ -281,7 +326,8 @@ Compilation To remove the stack just run this command in the same folder: docker-compose down -Compile scaphandre from source (GNU/Linux) + +Compile scaphandre from source (GNU/Linux) We recommand using this version of the rust toolchain or later: cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml Get the Grafana web UI password which is randomly generated. -kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
curl -s http://localhost:8080/metrics
Here you can see examples of graphs you can get thanks to scaphandre, the prometheus exporter, prometheus and grafana.
Depending on your kernel version, you could need to modprobe the module intel_rapl or intel_rapl_common before running scaphandre:
docker run -v /sys/class/powercap:/sys/class/powercap -v /proc:/proc -ti hubblo/scaphandre stdout -t 15
Since Debian Sid, Scaphandre is available as an official package, try:
sudo apt install scaphandre +
If not (yet) in your official packages repositories, on Debian or Ubuntu, you can directly use the available .deb package for Debian Bullseye or the package for Debian Bookworm.
.deb
# For Debian Bookworm +VERSION="1.0.1" ARCH="amd64" DIST="deb12" && \ +wget https://github.com/hubblo-org/scaphandre/releases/download/v${VERSION}/scaphandre_v${VERSION}-${DIST}_${ARCH}.deb && \ +dpkg -i scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb && \ +rm scaphandre_v${VERSION}\-${DIST}\_${ARCH}.deb +
Once you downloaded or built a binary, you’d run:
Here are some other ways to install scaphandre depending on your context:
Kudos to contributors who work on system packages, please have a try and/or contribute to:
!! Warning: Windows version of Scaphandre is still in early stage. !!
Download the package and install it as an administrator.
Download the latest exe installer from the release page and install it as an administrator.
For example, to run the prometheus-push exporter in the background and target the Prometheus Push Gateway server with ip address 198.51.100.5 using HTTPS on port 443 and a step to send metrics of 45s, without checking the certificate of the push gateway (remove that option if you have a properly signed TLS certificate):
198.51.100.5
sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto +sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto Ensure the service is started in Services.msc, start it by right clicking on it, then Start, otherwise. -To delete the service, you can do it in Services.msc, or: +To delete the service, you can do it in Services.msc, or: sc.exe delete Scaphandre Using an installer including a development version of the driver -If you are running a development version of the installer (which probably means a development version of the driver), you'll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. +If you are running a development version of the installer (which probably means a development version of the driver), you’ll need to enable Test Mode on Windows prior to proceed to this installation, then reboot. bcdedit.exe -set TESTSIGNING ON bcdedit.exe -set nointegritychecks on @@ -261,15 +305,16 @@ Troubleshooti An error such as scaphandre::sensors::msr_rapl: Failed to open device : HANDLE(-1) -means that the driver is not properly setup. Check it's state by running: +means that the driver is not properly setup. Check it’s state by running: driverquery /v | findstr capha If there is not item returned, the installation of the driver encountered an issue. If the service is STOPPED, there is also something wrong. Compilation -If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows -Run a complete stack with docker-compose -If you'd like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. +If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows + +Run a complete stack with docker-compose +If you’d like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana. Once you have cloned the repository, just move to the docker-compose folder and run the stack: cd docker-compose docker-compose up -d @@ -281,7 +326,8 @@ Compilation To remove the stack just run this command in the same folder: docker-compose down -Compile scaphandre from source (GNU/Linux) + +Compile scaphandre from source (GNU/Linux) We recommand using this version of the rust toolchain or later: cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml Get the Grafana web UI password which is randomly generated. -kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
sc.exe create Scaphandre binPath="C:\Program Files (x86)\scaphandre\scaphandre.exe prometheus-push -H 198.51.100.5 -s 45 -S https -p 443 --no-tls-check" DisplayName=Scaphandre start=auto
Ensure the service is started in Services.msc, start it by right clicking on it, then Start, otherwise.
To delete the service, you can do it in Services.msc, or:
sc.exe delete Scaphandre
If you are running a development version of the installer (which probably means a development version of the driver), you'll need to enable Test Mode on Windows prior to proceed to this installation, then reboot.
If you are running a development version of the installer (which probably means a development version of the driver), you’ll need to enable Test Mode on Windows prior to proceed to this installation, then reboot.
bcdedit.exe -set TESTSIGNING ON bcdedit.exe -set nointegritychecks on
An error such as
scaphandre::sensors::msr_rapl: Failed to open device : HANDLE(-1)
means that the driver is not properly setup. Check it's state by running:
means that the driver is not properly setup. Check it’s state by running:
driverquery /v | findstr capha
If there is not item returned, the installation of the driver encountered an issue.
If the service is STOPPED, there is also something wrong.
If you look for compiling Scaphandre and its driver yourself, see Compilation for Windows
If you'd like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana.
If you’d like to try scaphandre and see the data in a decent visualization tool, there is a docker-compose in the repository to install scaphandre along side with prometheus and grafana.
Once you have cloned the repository, just move to the docker-compose folder and run the stack:
cd docker-compose docker-compose up -d @@ -281,7 +326,8 @@ Compilation To remove the stack just run this command in the same folder: docker-compose down -Compile scaphandre from source (GNU/Linux) + +Compile scaphandre from source (GNU/Linux) We recommand using this version of the rust toolchain or later: cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml Get the Grafana web UI password which is randomly generated. -kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
To remove the stack just run this command in the same folder:
docker-compose down
We recommand using this version of the rust toolchain or later:
cargo --version cargo 1.48.0 (65cbdd2dc 2020-10-14) @@ -298,15 +344,17 @@ Compilation cargo build --release Binary path is target/release/scaphandre. -Compilation for Windows (experimental) + +Compilation for Windows (experimental) Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure. - + Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit. For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary : -cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install Parameters Service monitor parameters -NameDescriptionValue + + + +NameDescriptionValue + + serviceMonitor.enabledCreate ServiceMonitor Resource for scraping metrics using PrometheusOperatorfalse -serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" +serviceMonitor.namespaceThe namespace in which the ServiceMonitor will be created (if not set, default to namespace on which this chart is installed)"" serviceMonitor.intervalThe interval at which metrics should be scraped1m - + + + +Security Parameters + + + +NameDescriptionValue + + +securityContext.privilegedGives full host access, bypassing container isolation (can be needed to run on physical server)false +securityContext.runAsUserRun as root user to get proper permissions0 +securityContext.runAsGroupRun as root group to get proper permissions0 + + Install Prometheus Next we will install Prometheus which will scrape the metrics generated by Scaphandre. @@ -352,7 +419,7 @@ Install Grafa helm install grafana grafana/grafana --values docs_src/tutorials/grafana-helm-values.yaml
cargo build --release
Binary path is target/release/scaphandre.
target/release/scaphandre
Scaphandre, on Windows, needs a kernel driver to get the same metrics as it does with powercap on GNU/Linux. This driver is available on this repository. Please refer to this project to get either pre-compiled binaries (available soon) or to follow the compilation procedure.
Once you have a working driver, you can compile Scaphandre, with the Rust for Windows usual toolkit.
For now, all Scaphandre features are not supported on windows. Use the following command line to build the binary :
cargo build --no-default-features --features "prometheus json riemann" +cargo build --no-default-features --features "prometheus json riemann" -Don't forget to add the --release flag to build a binary suited for more than test and debug usecases. -Kubernetes +Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases. + +Kubernetes This tutorial uses Helm to install Scaphandre, Prometheus and Grafana. Install Scaphandre @@ -319,11 +367,30 @@ Install
cargo build --no-default-features --features "prometheus json riemann"
Don't forget to add the --release flag to build a binary suited for more than test and debug usecases.
--release
Don’t forget to add the --release flag to build a binary suited for more than test and debug usecases.
This tutorial uses Helm to install Scaphandre, Prometheus and Grafana.
serviceMonitor.enabled
false
serviceMonitor.namespace
""
serviceMonitor.interval
1m
securityContext.privileged
securityContext.runAsUser
0
securityContext.runAsGroup
Next we will install Prometheus which will scrape the metrics generated by Scaphandre.
Get the Grafana web UI password which is randomly generated.
kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode +kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode Create a port forwarding connection to the Grafana pod. kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem> Save and (re)start the virtual machine. -If you get this error: "error: unsupported configuration: 'virtiofs' requires shared memory", you might add this configuration section to the <domain> section. +If you get this error: “error: unsupported configuration: ‘virtiofs’ requires shared memory”, you might add this configuration section to the <domain> section. <memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
kubectl get secret grafana -o jsonpath="{.data.admin-password}" | base64 --decode
Create a port forwarding connection to the Grafana pod.
kubectl port-forward deploy/grafana 3000:3000 @@ -362,19 +429,20 @@ Cleaning up Deleting the Helm releases will remove all the resources we created. helm delete grafana prometheus scaphandre -Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) + +Propagate power consumption metrics from hypervisor to virtual machines (Qemu/KVM) Introduction -A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn't have access to power metrics. +A major pain point in measuring power consumption is doing so inside a virtual machine. A virtual machine usually doesn’t have access to power metrics. Scaphandre aims at solving that by enabling a communication between a scaphandre instance on the hypervisor/bare metal machine and another one running on the virtual machine. The scaphandre agent on the hypervisor will compute the metrics meaningful for that virtual machine and the one on the VM access those metrics to allow its user/administrator to use the data as if they had access to power metrics in the first place (as if they were on a bare metal machine). This allows to break opacity in a virtualization context, if you have access to the hypervisor, or in a public cloud context if the provider uses scaphandre on its hypervisors. - + How to This is working on Qemu/KVM hypervisors only. -The idea is to run the agent on the hypervisor, with the qemu exporter: +The idea is to run the agent on the hypervisor, with the qemu exporter: scaphandre qemu -More examples for a production ready setup will be added soon (systemd service, docker container, ...). If you think the documentation needs a refresh now, please contribute :) +More examples for a production ready setup will be added soon (systemd service, docker container, …). If you think the documentation needs a refresh now, please contribute :) For each virtual machine you want to give access to its metrics, create a tmpfs mountpoint: mount -t tmpfs tmpfs_DOMAIN_NAME /var/lib/libvirt/scaphandre/DOMAIN_NAME -o size=5m @@ -390,7 +458,7 @@ How to </filesystem>
Deleting the Helm releases will remove all the resources we created.
helm delete grafana prometheus scaphandre
<memoryBacking> <source type='memfd'/> <access mode='shared'/> @@ -402,28 +470,30 @@ How to You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus): scaphandre --vm prometheus -Please refer to the qemu exporter reference for more details. -Note: This how to is only suitable for a "manual" use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. -Get process-level power consumption in my grafana dashboard -Now we'll see how to get valuable data in a dashboard. Let's say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? +Please refer to the qemu exporter reference for more details. +Note: This how to is only suitable for a “manual” use case. For all automated systems like openstack or proxmox, some more work needs to be done to make the integration of those steps easier. + +Get process-level power consumption in my grafana dashboard +Now we’ll see how to get valuable data in a dashboard. Let’s say you want to track the power consumption of a given process or application in a dashboard and eventually set thresholds on it. WHat do you need to get that subset of the power consumption of the host visually ? You need basically 3 components for that: -scaphandre running with the prometheus exporter +scaphandre running with the prometheus exporter prometheus grafana -We'll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. +We’ll say that you already have a running prometheus server and an available grafana instance and that you have added prometheus as a datasource in grafana. How to get metrics per process as you may see here ? The metric that I need from the prometheus exporter to do that is: scaph_process_power_consumption_microwatts. This metric is a wallet for the power consumption of all the running processes on the host at a given time. This is a prometheus metrics, so you have labels to filter on the processes you are interested in. Currently the available labels are: instance, exe, job and pid. If I want to get power consumption (in Watts) for all processes related to nginx running on a host with ip 10.0.0.9 I may use that query, in grafana, based on the prometheus datasource: -scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
You can now run scaphandre to export the metrics with the exporter of your choice (here prometheus):
scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 +scaph_process_power_consumption_microwatts{cmdline=~".*nginx.*", instance="10.0.0.9:8080"} / 1000000 Here we assume that scaphandre/the prometheus exporter is running on port number 8080. Here is how it looks, creating a panel in grafana: - -Those labels are explained in much more detail here. -Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 + +Those labels are explained in much more detail here. + +Install Scaphandre with only Prometheus-push exporter compiled, for Prometheus Push Gateway, on RHEL 8 and 9 Manual installation Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally). RPM packages containing only those features are provided for RHEL 8 and 9 : @@ -434,17 +504,17 @@ Manua You can download it and install it just providing the right URL to dnf : dnf install -y URL -Then you'll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : +Then you’ll probably need to change its configuration to target the appropriate Push Gateway server. Edit the configuration file : vi /etc/scaphandre/prometheuspush Default options look like : -SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
Scaphandre can be compiled with a limited set of features. You have the choice to only install Scaphandre with prometheus-push exporter (alongside with stdout and json exporters, which might be useful locally).
RPM packages containing only those features are provided for RHEL 8 and 9 :
SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" +SCAPHANDRE_ARGS="prometheus-push -H localhost -S http" Those are prometheus-push exporter CLI options. Run the executable to get the reference of the options : /usr/bin/scaphandre-prometheuspush --help A simple configuration to target Push Gateway reachable on https://myserver.mydomain:PORT and send data every 30 seconds would look like : -SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" +SCAPHANDRE_ARGS="prometheus-push -H myserver.mydomain -S https -p PORT -s 30" Once the configuration is changed, you can restart the service and ensure it is enabled as well for next reboot : systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
systemctl restart scaphandre-prometheuspush && systemctl enable scaphandre-prometheuspush @@ -459,7 +529,7 @@
There are several metrics available at the host level in Scaphandre:
scaph_host_power_microwatts
scaph_host_energy_microjoules
energy_uj
scaph_host_rapl_psys_microjoules
Sensors are meant to:
With Stdout exporter, you can see all metrics available on your machine with flag --raw-metrics. -With prometheus exporter, all metrics have a HELP section provided on /metrics (or whatever suffix you choosed to expose them).
--raw-metrics
With Stdout exporter, you can see all metrics available on your machine with flag --raw-metrics. +With prometheus exporter, all metrics have a HELP section provided on /metrics (or whatever suffix you choosed to expose them).
Here are some key metrics that you will most probably be interested in:
scaph_process_power_consumption_microwatts{exe="$PROCESS_EXE",pid="$PROCESS_PID",cmdline="path/to/exe --and-maybe-options"}
For more details on that metric labels, see this section.
And some more deep metrics that you may want if you need to make more complex calculations and data processing:
scaph_socket_power_microwatts{socket_id="$SOCKET_ID"}
If your machine provides RAPL PSYS domain (see RAPL domains), you can get the raw energy counter for PSYS/platform with scaph_host_rapl_psys_microjoules. Note that scaph_host_power_microwatts is based on this PSYS counter if it is available.
Since 1.0.0 the following host metrics are availalable as well ;
scaph_host_swap_total_bytes
scaph_self_topo_procs_nb: Number of processes monitored by scaph
scaph_self_topo_procs_nb
scaph_self_socket_stats_nb{socket_id="SOCKET_ID"}: Number of CPUStat traces stored for each socket
scaph_self_socket_stats_nb{socket_id="SOCKET_ID"}
scaph_self_socket_records_nb{socket_id="SOCKET_ID"}: Number of energy consumption Records stored for each socket, with SOCKET_ID being the id of the socket measured
scaph_self_socket_records_nb{socket_id="SOCKET_ID"}
scaph_self_domain_records_nb{socket_id="SOCKET_ID",rapl_domain_name="RAPL_DOMAIN_NAME "}: Number of energy consumption Records stored for a Domain, where SOCKET_ID identifies the socket and RAPL_DOMAIN_NAME identifies the rapl domain measured on that socket
scaph_self_domain_records_nb{socket_id="SOCKET_ID",rapl_domain_name="RAPL_DOMAIN_NAME "}
cmdline
=~
Since 1.0.0 the following per-process metrics are available as well :
scaph_process_disk_total_read_bytes
The flag --containers enables Scaphandre to collect data about the running Docker containers or Kubernetes pods on the local machine. This way, it adds specific labels to make filtering processes power consumption metrics by their encapsulation in containers easier.
The flag –containers enables Scaphandre to collect data about the running Docker containers or Kubernetes pods on the local machine. This way, it adds specific labels to make filtering processes power consumption metrics by their encapsulation in containers easier.
Generic labels help to identify the container runtime and scheduler used (based on the content of /proc/PID/cgroup):
/proc/PID/cgroup
container_scheduler: possible values are docker or kubernetes. If this label is not attached to the metric, it means that scaphandre didn't manage to identify the container scheduler based on cgroups data.
container_scheduler
docker
kubernetes
container_scheduler: possible values are docker or kubernetes. If this label is not attached to the metric, it means that scaphandre didn’t manage to identify the container scheduler based on cgroups data.
Then the label container_runtime could be attached. The only possible value for now is containerd.
container_runtime
containerd
container_id is the ID scaphandre got from /proc/PID/cgroup for that container.
container_id
For Docker containers (if container_scheduler is set), available labels are :
You can launch the JSON exporter this way (running the default powercap_rapl sensor):
scaphandre json @@ -694,7 +771,7 @@ Usage scaphandre --no-header json --containers --max-top-consumers=15 | jq Since 1.0.0 you can filter the processes, either by their process name with --process-regex, or by the name of the container they run in with --container-regex (needs the flag --containers to be active as well). -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Write the metrics in the JSON format to a file or to stdout Usage: scaphandre json [OPTIONS] @@ -721,14 +798,15 @@ Usage -h, --help Print help -Metrics provided Scaphandre are documented here. -Prometheus exporter +Metrics provided Scaphandre are documented here. + +Prometheus exporter Usage You can launch the prometheus exporter this way (running the default powercap_rapl sensor): scaphandre prometheus -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: scaphandre prometheus -h scaphandre-prometheus Prometheus exporter exposes power consumption metrics on an http endpoint (/metrics is default) in prometheus accepted @@ -749,14 +827,43 @@ Usage -s, --suffix <suffix> url suffix to access metrics [default: metrics] With default options values, the metrics are exposed on http://localhost:8080/metrics. -Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor. -Metrics provided Scaphandre are documented here. -Qemu exporter -Computes energy consumption metrics for each Qemu/KVM virtual machine found on the host. -Exposes those metrics as filetrees compatible with the powercap_rapl sensor. -Note that this is still experimental. Metrics are already considered trustworthy, but there are discussions and tests to be performed about the acceptable ways to share the data with the guests/vms. Any feedback or thoughts about this are welcome. Please refer to the contributing section. +Metrics provided Scaphandre are documented here. + +PrometheusPush Exporter for Prometheus Push Gateway Usage +You can launch the prometheus exporter this way: +scaphandre prometheus-push + +As always exporter’s options can be displayed with -h: + scaphandre prometheus-push -h + Push metrics to Prometheus Push Gateway + + Usage: scaphandre prometheus-push [OPTIONS] + + Options: + -H, --host <HOST> IP address (v4 or v6) of the metrics endpoint for Prometheus [default: localhost] + -p, --port <PORT> TCP port of the metrics endpoint for Prometheus [default: 9091] + --suffix <SUFFIX> [default: metrics] + -S, --scheme <SCHEME> [default: http] + -s, --step <STEP> [default: 5] + --qemu Apply labels to metrics of processes that look like a Qemu/KVM virtual machine + --containers Apply labels to metrics of processes running as containers + -j, --job <JOB> Job name to apply as a label for pushed metrics [default: scaphandre] + --no-tls-check Don't verify remote TLS certificate (works with --scheme="https") + -h, --help Print help + +With default options values, the metrics are sent to http://localhost:9091/metrics +Metrics exposed +Metrics exposed are the same as the Prometheus (pull mode) exporter. +Push gateway’s grouping key for each host is in the form job/scaphandre/instance/${HOSTNAME} with HOSTNAME being the hostname of the host sending metrics. + +Qemu exporter +Computes energy consumption metrics for each Qemu/KVM virtual machine found on the host. +Exposes those metrics as filetrees compatible with the powercap_rapl sensor. +Note that this is still experimental. Metrics are already considered trustworthy, but there are discussions and tests to be performed about the acceptable ways to share the data with the guests/vms. Any feedback or thoughts about this are welcome. Please refer to the contributing section. +Usage Run the scaphandre with the qemu exporter on your bare metal hypervisor machine: @@ -781,11 +888,11 @@ Usage You can edit the vm properties using sudo virsh edit <DOMAIN_NAME> using your usual editor. But it is more convenient to use virtual-manager, as explained in the following screenshots. It also helps to define the correct syntax which probably depends from the qemu version. You can check that the above configuration is slightly different form the one below. a. Right click in the hardware menu: - + b. Enter the following parameters: - + c. XML generated as a result: - + Ensure the VM has been started once the configuration is applied, then mount the filesystem on the VM/guest: @@ -803,13 +910,14 @@ Usage -Riemann exporter - -Usage + +Riemann exporter + +Usage You can launch the Riemann exporter this way (running the default powercap_rapl sensor): scaphandre riemann -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Expose the metrics to a Riemann server Usage: scaphandre riemann [OPTIONS] @@ -851,18 +959,18 @@ Usage ; -*- mode: clojure; -*- ; vim: filetype=clojure -(logging/init {:file "riemann.log"}) +(logging/init {:file "riemann.log"}) ; Listen on the local interface over TCP (5555), UDP (5555), TLS/TCP (5554) and websockets ; (5556) -(let [host "0.0.0.0"] +(let [host "0.0.0.0"] (tcp-server {:host host}) (tcp-server {:host host :port 5554 :tls? true - :key "/client.key.pkcs8" - :cert "/client.pem" - :ca-cert "/CA.pem"}) + :key "/client.key.pkcs8" + :cert "/client.pem" + :ca-cert "/CA.pem"}) (udp-server {:host host}) (ws-server {:host host})) @@ -878,16 +986,17 @@ Usage ; Log expired events. (expired - (fn [event] (info "expired" event)))))) + (fn [event] (info "expired" event)))))) -Metrics exposed -Metrics provided Scaphandre are documented here. +Metrics exposed +Metrics provided Scaphandre are documented here. There is only one exception about process_power_consumption_microwatts each process has a service name process_power_consumption_microwatts_pid_exe. As an example, process consumption can be retrieved using the following Riemann query: -(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") +(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") -Stdout exporter -Usage + +Stdout exporter +Usage You can launch the stdout exporter this way (running the default powercap_rapl sensor): scaphandre stdout @@ -905,12 +1014,12 @@ Usage You can filter the processes to display with -r. A warning will be risen if this option is used with -p at the same time. In such case, -p behavior is disabled. The -r expected parameter is a regular expression. Details can be found here and tested here. -Here is how to display power data for the 'scaphandre' process: +Here is how to display power data for the ‘scaphandre’ process: scaphandre stdout -r 'scaphandre' -Metrics provided Scaphandre are documented here. -Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it's own format and might not show you all available metrics. -As always exporter's options can be displayed with -h: +Metrics provided Scaphandre are documented here. +Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it’s own format and might not show you all available metrics. +As always exporter’s options can be displayed with -h: Write the metrics to the terminal Usage: scaphandre stdout [OPTIONS] @@ -924,16 +1033,17 @@ Usage -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine --raw-metrics Display metrics with their names -h, --help Print help -Warp10 exporter - -Usage + +Warp10 exporter + +Usage You can launch the Warp10 exporter this way (running the default powercap_rapl sensor): scaphandre warp10 You need a token to be able to push data to a warp10 instance. The SCAPH_WARP10_WRITE_TOKEN env var can be used to make it available to scaphandre. Please refer to the warp10 documentation to know how to get the token in the first place. -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -941,17 +1051,18 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help With default options values, the metrics are sent to http://localhost:8080 every 60 seconds -Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor. -Metrics provided Scaphandre are documented here. -MSR_RAPL sensor +Metrics provided Scaphandre are documented here. + +MSR_RAPL sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -959,7 +1070,7 @@ Pre-requesites< Intel and AMD x86 CPUs, produced after 2012 (or some laptop cpu prior to 2012) This sensor needs the RAPL MSR-based driver to be installed. -Usage +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -973,7 +1084,8 @@ E TODO Troubleshooting TODO -Powercap_rapl sensor + +Powercap_rapl sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -986,8 +1098,8 @@ Pre-requesi For AMD processors, it seems that powercap/rapl will work only since kernel 5.8 and 5.11 for family 19h. Energy consumption data can be directly collected on a physical machine only. -To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. -Usage +To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s powercap_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -1014,66 +1126,53 @@ - powercap: make attributes only readable by root Therefor, the user running scaphandre needs to have read access to energy_uj files in /sys/class/powercap. -You can run the init.sh script to apply appropriate permissions to the required files. -MSR_RAPL sensor -Pre-requesites -At the time those lines are written, this sensor works only on: - -OS: Windows 10/Windows Server 2016, Windows Server 2019 -Intel and AMD x86 CPUs, produced after 2012 (or some laptop cpu prior to 2012) - -This sensor needs the RAPL MSR-based driver to be installed. -Usage -To explicitely call the powercap_rapl sensor from the command line use: -scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use - -You can see arguments available from the cli for this sensors with: -scaphandre -s msr_rapl -h - -Please refer to doc.rs code documentation for more details. -Options available -TODO -Environment variables -TODO -Troubleshooting -TODO -Why ? +You can run the init.sh script to apply appropriate permissions to the required files. + +Why ? We are facing the biggest challenge of mankind history: to make our activities sustainable enough to not jeopardize our future. - + To match the Paris agreement objective of not going further than +2 Celcius degrees on average in 2100, we need to transform our industries. The tech industry is no exception and we need to make sure that its benefits are not cancelled (or worse) by its negative impact. -Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn't give fine graned data regarding applications/processes power consumption but only the host power consumption. -This is even harder in a virtualization environement or as public cloud customers. -Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions based data (because it's all we got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years. -Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well understood way to precisely measure the energy consumption and make it useful to take soberness decisions. -Note that the greenhouse gazes emissions related to this energy consumption depends on the energetic mix of your country. You may find valuable data about that on Electricity Map. -Compatibility +Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn’t give fine-grained data regarding applications/processes power consumption but only the host power consumption. +This is even harder in a virtualization environment or as public cloud customers. +Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions-based data (because it’s all we’ve got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years. +Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well-understood way to precisely measure the energy consumption and make it useful to take soberness decisions. +Note that the greenhouse gas emissions related to this energy consumption depends on the energy mix of your country. You may find valuable data about that on Electricity Map. + +Compatibility Scaphandre intends to provide multiple ways to gather power consumption metrics and make understanding tech services footprint possible in many situations. Depending on how you use scaphandre, you may have some restrictions. To summarize, scaphandre should provide two ways to estimate the power consumption of a service, process or machine. Either by measuring it, using software interfaces that give access to hardware metrics, or by estimating it if measuring is not an option (this is a planned feature, not yet implemented as those lines are written, in december 2020). -In scaphandre, the code responsible to collect the power consumption data before any further processing is grouped in components called sensors. If you want more details about scaphandre structure, here are the explanations. -On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn't work in all contexts. -On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR's enables you to do (almost) the same. -SensorIntel x86 bare metalAMD x86 bare metalARM bare metalVirtual MachinePublic cloud instanceContainer -PowercapRAPL (GNU/Linux only)YesYes ⚠️ kernel > 5.11 requiredWe don't know yetYes, if on a qemu/KVM hypervisor that runs scaphandre and the Qemu exporterNo, until your cloud provider uses scaphandre on its hypervisorsDepends on what you want -MsrRAPL (Windows only)YesProbable yes (not tested yet, if you have windows operated AMD gear, please consider contributingNoNot yet, depends on improvements on the MsrRAPL sensors and overall windows/hypervisors support in ScaphandreNo, until your cloud provider uses scaphandre on its hypervisorsMight work, not tested yet. If you want to join us in this journey, please consider contributing +In scaphandre, the code responsible to collect the power consumption data before any further processing is grouped in components called sensors. If you want more details about scaphandre structure, here are the explanations. +On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn’t work in all contexts. +On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR’s enables you to do (almost) the same. + + + +SensorIntel x86 bare metalAMD x86 bare metalARM bare metalVirtual MachinePublic cloud instanceContainer + + +PowercapRAPL (GNU/Linux only)YesYes ⚠️ kernel > 5.11 requiredWe don’t know yetYes, if on a qemu/KVM hypervisor that runs scaphandre and the Qemu exporterNo, until your cloud provider uses scaphandre on its hypervisorsDepends on what you want +MsrRAPL (Windows only)YesProbable yes (not tested yet, if you have windows operated AMD gear, please consider contributingNoNot yet, depends on improvements on the MsrRAPL sensors and overall windows/hypervisors support in ScaphandreNo, until your cloud provider uses scaphandre on its hypervisorsMight work, not tested yet. If you want to join us in this journey, please consider contributing Future estimation based sensorFuture YesFuture YesFuture YesFuture YesFuture YesFuture Yes - + + Checking RAPL is available on your CPU -Sensors including "RAPL" in their name rely on RAPL. -The pts and pln feature flags ("Intel Package Thermal Status" and "Intel Power Limit Notification" respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : -egrep "(pts|pln)" /proc/cpuinfo +Sensors including “RAPL” in their name rely on RAPL. +The pts and pln feature flags (“Intel Package Thermal Status” and “Intel Power Limit Notification” respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : +egrep "(pts|pln)" /proc/cpuinfo -Troubleshooting + +Troubleshooting I get a permission denied error when I run scaphandre, no matter what is the exporter -Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. +Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. To ensure this is your issue and fix that quickly you can run the init.sh script: bash init.sh Then run scaphandre. If it does not work, the issue is somewhere else. I get a no such device error, the intel_rapl of intel_rapl_common kernel modules are present -It can mean that your cpu doesn't support RAPL. Please refer to the compatibility section to be sure. -I can't mount the required kernel modules, getting a Could'nt find XXX modules error +It can mean that your cpu doesn’t support RAPL. Please refer to the compatibility section to be sure. +I can’t mount the required kernel modules, getting a Could'nt find XXX modules error If you are in a situation comparable to this one, you may need to install additional packages. On ubuntu 20.01 and 20.10, try to install linux-modules-extra-$(uname -r) with apt. Then you should be able to modprobe intel_rapl_common. On an AMD cpu machine, I get the following stracktrace @@ -1104,7 +1203,7 @@ -We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won't probably work as the drivers needed to feed powercap with rapl data are not present. +We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won’t probably work as the drivers needed to feed powercap with rapl data are not present. Trying to build the project I get this error error: linker `cc` not found | @@ -1117,7 +1216,8 @@
scaphandre --no-header json --containers --max-top-consumers=15 | jq
Since 1.0.0 you can filter the processes, either by their process name with --process-regex, or by the name of the container they run in with --container-regex (needs the flag --containers to be active as well).
--process-regex
--container-regex
--containers
As always exporter's options can be displayed with -h:
-h
As always exporter’s options can be displayed with -h:
Write the metrics in the JSON format to a file or to stdout Usage: scaphandre json [OPTIONS] @@ -721,14 +798,15 @@ Usage -h, --help Print help
Metrics provided Scaphandre are documented here.
You can launch the prometheus exporter this way (running the default powercap_rapl sensor):
scaphandre prometheus
scaphandre prometheus -h scaphandre-prometheus Prometheus exporter exposes power consumption metrics on an http endpoint (/metrics is default) in prometheus accepted @@ -749,14 +827,43 @@ Usage -s, --suffix <suffix> url suffix to access metrics [default: metrics]
With default options values, the metrics are exposed on http://localhost:8080/metrics.
Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +
qemu-system*
Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor.
Computes energy consumption metrics for each Qemu/KVM virtual machine found on the host. -Exposes those metrics as filetrees compatible with the powercap_rapl sensor.
Note that this is still experimental. Metrics are already considered trustworthy, but there are discussions and tests to be performed about the acceptable ways to share the data with the guests/vms. Any feedback or thoughts about this are welcome. Please refer to the contributing section.
You can launch the prometheus exporter this way:
scaphandre prometheus-push +
scaphandre prometheus-push -h + Push metrics to Prometheus Push Gateway + + Usage: scaphandre prometheus-push [OPTIONS] + + Options: + -H, --host <HOST> IP address (v4 or v6) of the metrics endpoint for Prometheus [default: localhost] + -p, --port <PORT> TCP port of the metrics endpoint for Prometheus [default: 9091] + --suffix <SUFFIX> [default: metrics] + -S, --scheme <SCHEME> [default: http] + -s, --step <STEP> [default: 5] + --qemu Apply labels to metrics of processes that look like a Qemu/KVM virtual machine + --containers Apply labels to metrics of processes running as containers + -j, --job <JOB> Job name to apply as a label for pushed metrics [default: scaphandre] + --no-tls-check Don't verify remote TLS certificate (works with --scheme="https") + -h, --help Print help +
With default options values, the metrics are sent to http://localhost:9091/metrics
Metrics exposed are the same as the Prometheus (pull mode) exporter.
Push gateway’s grouping key for each host is in the form job/scaphandre/instance/${HOSTNAME} with HOSTNAME being the hostname of the host sending metrics.
job/scaphandre/instance/${HOSTNAME}
Computes energy consumption metrics for each Qemu/KVM virtual machine found on the host. +Exposes those metrics as filetrees compatible with the powercap_rapl sensor.
Run the scaphandre with the qemu exporter on your bare metal hypervisor machine:
You can edit the vm properties using sudo virsh edit <DOMAIN_NAME> using your usual editor. But it is more convenient to use virtual-manager, as explained in the following screenshots.
sudo virsh edit <DOMAIN_NAME>
It also helps to define the correct syntax which probably depends from the qemu version. You can check that the above configuration is slightly different form the one below.
a. Right click in the hardware menu: -
b. Enter the following parameters: -
c. XML generated as a result: -
Ensure the VM has been started once the configuration is applied, then mount the filesystem on the VM/guest:
You can launch the Riemann exporter this way (running the default powercap_rapl sensor):
scaphandre riemann
Expose the metrics to a Riemann server Usage: scaphandre riemann [OPTIONS] @@ -851,18 +959,18 @@ Usage ; -*- mode: clojure; -*- ; vim: filetype=clojure -(logging/init {:file "riemann.log"}) +(logging/init {:file "riemann.log"}) ; Listen on the local interface over TCP (5555), UDP (5555), TLS/TCP (5554) and websockets ; (5556) -(let [host "0.0.0.0"] +(let [host "0.0.0.0"] (tcp-server {:host host}) (tcp-server {:host host :port 5554 :tls? true - :key "/client.key.pkcs8" - :cert "/client.pem" - :ca-cert "/CA.pem"}) + :key "/client.key.pkcs8" + :cert "/client.pem" + :ca-cert "/CA.pem"}) (udp-server {:host host}) (ws-server {:host host})) @@ -878,16 +986,17 @@ Usage ; Log expired events. (expired - (fn [event] (info "expired" event)))))) + (fn [event] (info "expired" event)))))) -Metrics exposed -Metrics provided Scaphandre are documented here. +Metrics exposed +Metrics provided Scaphandre are documented here. There is only one exception about process_power_consumption_microwatts each process has a service name process_power_consumption_microwatts_pid_exe. As an example, process consumption can be retrieved using the following Riemann query: -(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") +(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") -Stdout exporter -Usage + +Stdout exporter +Usage You can launch the stdout exporter this way (running the default powercap_rapl sensor): scaphandre stdout @@ -905,12 +1014,12 @@ Usage You can filter the processes to display with -r. A warning will be risen if this option is used with -p at the same time. In such case, -p behavior is disabled. The -r expected parameter is a regular expression. Details can be found here and tested here. -Here is how to display power data for the 'scaphandre' process: +Here is how to display power data for the ‘scaphandre’ process: scaphandre stdout -r 'scaphandre' -Metrics provided Scaphandre are documented here. -Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it's own format and might not show you all available metrics. -As always exporter's options can be displayed with -h: +Metrics provided Scaphandre are documented here. +Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it’s own format and might not show you all available metrics. +As always exporter’s options can be displayed with -h: Write the metrics to the terminal Usage: scaphandre stdout [OPTIONS] @@ -924,16 +1033,17 @@ Usage -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine --raw-metrics Display metrics with their names -h, --help Print help -Warp10 exporter - -Usage + +Warp10 exporter + +Usage You can launch the Warp10 exporter this way (running the default powercap_rapl sensor): scaphandre warp10 You need a token to be able to push data to a warp10 instance. The SCAPH_WARP10_WRITE_TOKEN env var can be used to make it available to scaphandre. Please refer to the warp10 documentation to know how to get the token in the first place. -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -941,17 +1051,18 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help With default options values, the metrics are sent to http://localhost:8080 every 60 seconds -Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor. -Metrics provided Scaphandre are documented here. -MSR_RAPL sensor +Metrics provided Scaphandre are documented here. + +MSR_RAPL sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -959,7 +1070,7 @@ Pre-requesites< Intel and AMD x86 CPUs, produced after 2012 (or some laptop cpu prior to 2012) This sensor needs the RAPL MSR-based driver to be installed. -Usage +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -973,7 +1084,8 @@ E TODO Troubleshooting TODO -Powercap_rapl sensor + +Powercap_rapl sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -986,8 +1098,8 @@ Pre-requesi For AMD processors, it seems that powercap/rapl will work only since kernel 5.8 and 5.11 for family 19h. Energy consumption data can be directly collected on a physical machine only. -To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. -Usage +To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s powercap_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -1014,66 +1126,53 @@ - powercap: make attributes only readable by root Therefor, the user running scaphandre needs to have read access to energy_uj files in /sys/class/powercap. -You can run the init.sh script to apply appropriate permissions to the required files. -MSR_RAPL sensor -Pre-requesites -At the time those lines are written, this sensor works only on: - -OS: Windows 10/Windows Server 2016, Windows Server 2019 -Intel and AMD x86 CPUs, produced after 2012 (or some laptop cpu prior to 2012) - -This sensor needs the RAPL MSR-based driver to be installed. -Usage -To explicitely call the powercap_rapl sensor from the command line use: -scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use - -You can see arguments available from the cli for this sensors with: -scaphandre -s msr_rapl -h - -Please refer to doc.rs code documentation for more details. -Options available -TODO -Environment variables -TODO -Troubleshooting -TODO -Why ? +You can run the init.sh script to apply appropriate permissions to the required files. + +Why ? We are facing the biggest challenge of mankind history: to make our activities sustainable enough to not jeopardize our future. - + To match the Paris agreement objective of not going further than +2 Celcius degrees on average in 2100, we need to transform our industries. The tech industry is no exception and we need to make sure that its benefits are not cancelled (or worse) by its negative impact. -Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn't give fine graned data regarding applications/processes power consumption but only the host power consumption. -This is even harder in a virtualization environement or as public cloud customers. -Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions based data (because it's all we got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years. -Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well understood way to precisely measure the energy consumption and make it useful to take soberness decisions. -Note that the greenhouse gazes emissions related to this energy consumption depends on the energetic mix of your country. You may find valuable data about that on Electricity Map. -Compatibility +Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn’t give fine-grained data regarding applications/processes power consumption but only the host power consumption. +This is even harder in a virtualization environment or as public cloud customers. +Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions-based data (because it’s all we’ve got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years. +Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well-understood way to precisely measure the energy consumption and make it useful to take soberness decisions. +Note that the greenhouse gas emissions related to this energy consumption depends on the energy mix of your country. You may find valuable data about that on Electricity Map. + +Compatibility Scaphandre intends to provide multiple ways to gather power consumption metrics and make understanding tech services footprint possible in many situations. Depending on how you use scaphandre, you may have some restrictions. To summarize, scaphandre should provide two ways to estimate the power consumption of a service, process or machine. Either by measuring it, using software interfaces that give access to hardware metrics, or by estimating it if measuring is not an option (this is a planned feature, not yet implemented as those lines are written, in december 2020). -In scaphandre, the code responsible to collect the power consumption data before any further processing is grouped in components called sensors. If you want more details about scaphandre structure, here are the explanations. -On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn't work in all contexts. -On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR's enables you to do (almost) the same. -SensorIntel x86 bare metalAMD x86 bare metalARM bare metalVirtual MachinePublic cloud instanceContainer -PowercapRAPL (GNU/Linux only)YesYes ⚠️ kernel > 5.11 requiredWe don't know yetYes, if on a qemu/KVM hypervisor that runs scaphandre and the Qemu exporterNo, until your cloud provider uses scaphandre on its hypervisorsDepends on what you want -MsrRAPL (Windows only)YesProbable yes (not tested yet, if you have windows operated AMD gear, please consider contributingNoNot yet, depends on improvements on the MsrRAPL sensors and overall windows/hypervisors support in ScaphandreNo, until your cloud provider uses scaphandre on its hypervisorsMight work, not tested yet. If you want to join us in this journey, please consider contributing +In scaphandre, the code responsible to collect the power consumption data before any further processing is grouped in components called sensors. If you want more details about scaphandre structure, here are the explanations. +On GNU/Linux PowercapRAPL sensor enables you to measure the power consumption, but it doesn’t work in all contexts. +On Windows, the MsrRAPL sensor, coupled with the driver responsible to read RAPL MSR’s enables you to do (almost) the same. + + + +SensorIntel x86 bare metalAMD x86 bare metalARM bare metalVirtual MachinePublic cloud instanceContainer + + +PowercapRAPL (GNU/Linux only)YesYes ⚠️ kernel > 5.11 requiredWe don’t know yetYes, if on a qemu/KVM hypervisor that runs scaphandre and the Qemu exporterNo, until your cloud provider uses scaphandre on its hypervisorsDepends on what you want +MsrRAPL (Windows only)YesProbable yes (not tested yet, if you have windows operated AMD gear, please consider contributingNoNot yet, depends on improvements on the MsrRAPL sensors and overall windows/hypervisors support in ScaphandreNo, until your cloud provider uses scaphandre on its hypervisorsMight work, not tested yet. If you want to join us in this journey, please consider contributing Future estimation based sensorFuture YesFuture YesFuture YesFuture YesFuture YesFuture Yes - + + Checking RAPL is available on your CPU -Sensors including "RAPL" in their name rely on RAPL. -The pts and pln feature flags ("Intel Package Thermal Status" and "Intel Power Limit Notification" respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : -egrep "(pts|pln)" /proc/cpuinfo +Sensors including “RAPL” in their name rely on RAPL. +The pts and pln feature flags (“Intel Package Thermal Status” and “Intel Power Limit Notification” respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : +egrep "(pts|pln)" /proc/cpuinfo -Troubleshooting + +Troubleshooting I get a permission denied error when I run scaphandre, no matter what is the exporter -Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. +Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. To ensure this is your issue and fix that quickly you can run the init.sh script: bash init.sh Then run scaphandre. If it does not work, the issue is somewhere else. I get a no such device error, the intel_rapl of intel_rapl_common kernel modules are present -It can mean that your cpu doesn't support RAPL. Please refer to the compatibility section to be sure. -I can't mount the required kernel modules, getting a Could'nt find XXX modules error +It can mean that your cpu doesn’t support RAPL. Please refer to the compatibility section to be sure. +I can’t mount the required kernel modules, getting a Could'nt find XXX modules error If you are in a situation comparable to this one, you may need to install additional packages. On ubuntu 20.01 and 20.10, try to install linux-modules-extra-$(uname -r) with apt. Then you should be able to modprobe intel_rapl_common. On an AMD cpu machine, I get the following stracktrace @@ -1104,7 +1203,7 @@ -We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won't probably work as the drivers needed to feed powercap with rapl data are not present. +We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won’t probably work as the drivers needed to feed powercap with rapl data are not present. Trying to build the project I get this error error: linker `cc` not found | @@ -1117,7 +1216,8 @@
; -*- mode: clojure; -*- ; vim: filetype=clojure -(logging/init {:file "riemann.log"}) +(logging/init {:file "riemann.log"}) ; Listen on the local interface over TCP (5555), UDP (5555), TLS/TCP (5554) and websockets ; (5556) -(let [host "0.0.0.0"] +(let [host "0.0.0.0"] (tcp-server {:host host}) (tcp-server {:host host :port 5554 :tls? true - :key "/client.key.pkcs8" - :cert "/client.pem" - :ca-cert "/CA.pem"}) + :key "/client.key.pkcs8" + :cert "/client.pem" + :ca-cert "/CA.pem"}) (udp-server {:host host}) (ws-server {:host host})) @@ -878,16 +986,17 @@ Usage ; Log expired events. (expired - (fn [event] (info "expired" event)))))) + (fn [event] (info "expired" event))))))
There is only one exception about process_power_consumption_microwatts each process has a service name process_power_consumption_microwatts_pid_exe.
process_power_consumption_microwatts
process_power_consumption_microwatts_pid_exe
As an example, process consumption can be retrieved using the following Riemann query:
(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") +(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") -Stdout exporter -Usage + +Stdout exporter +Usage You can launch the stdout exporter this way (running the default powercap_rapl sensor): scaphandre stdout @@ -905,12 +1014,12 @@ Usage You can filter the processes to display with -r. A warning will be risen if this option is used with -p at the same time. In such case, -p behavior is disabled. The -r expected parameter is a regular expression. Details can be found here and tested here. -Here is how to display power data for the 'scaphandre' process: +Here is how to display power data for the ‘scaphandre’ process: scaphandre stdout -r 'scaphandre' -Metrics provided Scaphandre are documented here. -Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it's own format and might not show you all available metrics. -As always exporter's options can be displayed with -h: +Metrics provided Scaphandre are documented here. +Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it’s own format and might not show you all available metrics. +As always exporter’s options can be displayed with -h: Write the metrics to the terminal Usage: scaphandre stdout [OPTIONS] @@ -924,16 +1033,17 @@ Usage -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine --raw-metrics Display metrics with their names -h, --help Print help -Warp10 exporter - -Usage + +Warp10 exporter + +Usage You can launch the Warp10 exporter this way (running the default powercap_rapl sensor): scaphandre warp10 You need a token to be able to push data to a warp10 instance. The SCAPH_WARP10_WRITE_TOKEN env var can be used to make it available to scaphandre. Please refer to the warp10 documentation to know how to get the token in the first place. -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -941,17 +1051,18 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help With default options values, the metrics are sent to http://localhost:8080 every 60 seconds -Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor. -Metrics provided Scaphandre are documented here. -MSR_RAPL sensor +Metrics provided Scaphandre are documented here. + +MSR_RAPL sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -959,7 +1070,7 @@ Pre-requesites< Intel and AMD x86 CPUs, produced after 2012 (or some laptop cpu prior to 2012) This sensor needs the RAPL MSR-based driver to be installed. -Usage +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -973,7 +1084,8 @@ E TODO Troubleshooting TODO -Powercap_rapl sensor + +Powercap_rapl sensor Pre-requesites At the time those lines are written, this sensor works only on: @@ -986,8 +1098,8 @@ Pre-requesi For AMD processors, it seems that powercap/rapl will work only since kernel 5.8 and 5.11 for family 19h. Energy consumption data can be directly collected on a physical machine only. -To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. -Usage +To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled. +Usage To explicitely call the powercap_rapl sensor from the command line use: scaphandre -s powercap_rapl EXPORTER # EXPORTER being the exporter name you want to use @@ -1014,66 +1126,53 @@ - powercap: make attributes only readable by root
(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre")
You can launch the stdout exporter this way (running the default powercap_rapl sensor):
scaphandre stdout
You can filter the processes to display with -r. A warning will be risen if this option is used with -p at the same time. In such case, -p behavior is disabled.
-r
-p
The -r expected parameter is a regular expression. Details can be found here and tested here.
Here is how to display power data for the 'scaphandre' process:
Here is how to display power data for the ‘scaphandre’ process:
scaphandre stdout -r 'scaphandre'
Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it's own format and might not show you all available metrics.
Since 1.0.0 the flag --raw-metrics displays all metrics available for the host, as a parseable list. This might be useful to list metrics that you would like to fetch afterwards in your monitoring dashboard. Without this flag enabled, Stdout exporter has it’s own format and might not show you all available metrics.
Write the metrics to the terminal Usage: scaphandre stdout [OPTIONS] @@ -924,16 +1033,17 @@ Usage -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine --raw-metrics Display metrics with their names -h, --help Print help
You can launch the Warp10 exporter this way (running the default powercap_rapl sensor):
scaphandre warp10
You need a token to be able to push data to a warp10 instance. The SCAPH_WARP10_WRITE_TOKEN env var can be used to make it available to scaphandre. Please refer to the warp10 documentation to know how to get the token in the first place.
SCAPH_WARP10_WRITE_TOKEN
Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -941,17 +1051,18 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help
With default options values, the metrics are sent to http://localhost:8080 every 60 seconds
At the time those lines are written, this sensor works only on:
This sensor needs the RAPL MSR-based driver to be installed.
To explicitely call the powercap_rapl sensor from the command line use:
scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use
TODO
For AMD processors, it seems that powercap/rapl will work only since kernel 5.8 and 5.11 for family 19h.
Energy consumption data can be directly collected on a physical machine only.
To collect energy consumption on a virtual machine, you may first collect power consumption data from the hypervisor thanks to the qemu exporter and then collect those metrics in the virtual machine thanks to this sensor, with --vm flag enabled.
scaphandre -s powercap_rapl EXPORTER # EXPORTER being the exporter name you want to use
Therefor, the user running scaphandre needs to have read access to energy_uj files in /sys/class/powercap.
You can run the init.sh script to apply appropriate permissions to the required files.
scaphandre -s msr_rapl EXPORTER # EXPORTER being the exporter name you want to use -
You can see arguments available from the cli for this sensors with:
scaphandre -s msr_rapl -h -
Please refer to doc.rs code documentation for more details.
We are facing the biggest challenge of mankind history: to make our activities sustainable enough to not jeopardize our future.
To match the Paris agreement objective of not going further than +2 Celcius degrees on average in 2100, we need to transform our industries. The tech industry is no exception and we need to make sure that its benefits are not cancelled (or worse) by its negative impact.
Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn't give fine graned data regarding applications/processes power consumption but only the host power consumption. -This is even harder in a virtualization environement or as public cloud customers.
Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions based data (because it's all we got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years.
Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well understood way to precisely measure the energy consumption and make it useful to take soberness decisions.
Note that the greenhouse gazes emissions related to this energy consumption depends on the energetic mix of your country. You may find valuable data about that on Electricity Map.
Measuring power consumption in tech services infrastructures is not as easy as it seems. We often rely on physical devices to do that and need to build in-house data pipelines to get those metrics useful. Furthermore this doesn’t give fine-grained data regarding applications/processes power consumption but only the host power consumption. +This is even harder in a virtualization environment or as public cloud customers.
Even recent scientific researches about tech energy consumption rely on statistical, both large and narrowed scale, assumptions-based data (because it’s all we’ve got). Despite their weaknesses, they also all agree on the fact that the current consumption of datacenters and the Internet will increase drastically in the following years.
Scaphandre aims to initiate a collaboration of tech companies and enthusiasts to provide an easy, lightweight, robust and well-understood way to precisely measure the energy consumption and make it useful to take soberness decisions.
Note that the greenhouse gas emissions related to this energy consumption depends on the energy mix of your country. You may find valuable data about that on Electricity Map.
egrep "(pts|pln)" /proc/cpuinfo +Sensors including “RAPL” in their name rely on RAPL. +The pts and pln feature flags (“Intel Package Thermal Status” and “Intel Power Limit Notification” respectively) seem to indicate that RAPL is supported on a CPU. On GNU/Linux, you could be sure of their presence, if this command succeds and matches : +egrep "(pts|pln)" /proc/cpuinfo -Troubleshooting + +Troubleshooting I get a permission denied error when I run scaphandre, no matter what is the exporter -Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. +Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root. To ensure this is your issue and fix that quickly you can run the init.sh script: bash init.sh Then run scaphandre. If it does not work, the issue is somewhere else. I get a no such device error, the intel_rapl of intel_rapl_common kernel modules are present -It can mean that your cpu doesn't support RAPL. Please refer to the compatibility section to be sure. -I can't mount the required kernel modules, getting a Could'nt find XXX modules error +It can mean that your cpu doesn’t support RAPL. Please refer to the compatibility section to be sure. +I can’t mount the required kernel modules, getting a Could'nt find XXX modules error If you are in a situation comparable to this one, you may need to install additional packages. On ubuntu 20.01 and 20.10, try to install linux-modules-extra-$(uname -r) with apt. Then you should be able to modprobe intel_rapl_common. On an AMD cpu machine, I get the following stracktrace @@ -1104,7 +1203,7 @@
Since Linux kernel 5.10 (late 2020), the energy counters files that the PowercapRAPL sensor uses, are owned by root.
To ensure this is your issue and fix that quickly you can run the init.sh script:
bash init.sh
Then run scaphandre. If it does not work, the issue is somewhere else.
It can mean that your cpu doesn't support RAPL. Please refer to the compatibility section to be sure.
Could'nt find XXX modules
It can mean that your cpu doesn’t support RAPL. Please refer to the compatibility section to be sure.
If you are in a situation comparable to this one, you may need to install additional packages.
On ubuntu 20.01 and 20.10, try to install linux-modules-extra-$(uname -r) with apt. Then you should be able to modprobe intel_rapl_common.
linux-modules-extra-$(uname -r)
modprobe intel_rapl_common
We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won't probably work as the drivers needed to feed powercap with rapl data are not present.
We verified that scaphandre (and especially the powercap_rapl sensor) works on AMD Zen processors with a Linux kernel 5.11 or later. Before that kernel version, it won’t probably work as the drivers needed to feed powercap with rapl data are not present.
error: linker `cc` not found | @@ -1117,7 +1216,8 @@
Feel free to propose pull requests, or open new discussions or issues at will. Scaphandre is a collaborative project and all opinions and propositions shall be heard and studied. The contributions will be received with kindness, gratitude and with an open mind. Remember that we are all dwarfs standing on the shoulders of giants. We all have to learn from others and to give back, with due mutual respect.
Contributions may take multiple forms:
This project intends to use conventional commit messages and the gitflow workflow.
Please open your pull requests on the dev branch :)
Scaphandre is a not only a tool, but a framework. Modules dedicated to collect energy consumption data from the host are called Sensors. -Modules that are dedicated to send this data to a given channel or remote system are called Exporters. New Sensors and Exporters are going to be created and all contributions are welcome. For more on the internal structure please jump here.
Scaphandre is a not only a tool, but a framework. Modules dedicated to collect energy consumption data from the host are called Sensors. +Modules that are dedicated to send this data to a given channel or remote system are called Exporters. New Sensors and Exporters are going to be created and all contributions are welcome. For more on the internal structure please jump here.
Documentation source files are in docs_src, edit the content there and propose pull-requests on the scaphandre repository as if it was a code pull-request.
docs_src
Here is how to build and publish the documentation after a change. First download mdbook, the static site generator we use for the documentation website:
cargo install mdbook
Then fork the scaphandre-documentation repository and clone the resulting repository locally.
You can also serve the current content locally to see your changes before commit:
mdbook serve
Write the metrics in the JSON format to a file or to stdout Usage: scaphandre json [OPTIONS] @@ -196,11 +229,11 @@ Usage - + - - + + @@ -210,17 +243,38 @@ Usage - + - - + +
scaphandre prometheus -h scaphandre-prometheus Prometheus exporter exposes power consumption metrics on an http endpoint (/metrics is default) in prometheus accepted @@ -168,7 +201,7 @@ Usage -s, --suffix <suffix> url suffix to access metrics [default: metrics]
Computes energy consumption metrics for each Qemu/KVM virtual machine found on the host. @@ -170,11 +203,11 @@
Expose the metrics to a Riemann server Usage: scaphandre riemann [OPTIONS] @@ -189,18 +222,18 @@ Usage ; -*- mode: clojure; -*- ; vim: filetype=clojure -(logging/init {:file "riemann.log"}) +(logging/init {:file "riemann.log"}) ; Listen on the local interface over TCP (5555), UDP (5555), TLS/TCP (5554) and websockets ; (5556) -(let [host "0.0.0.0"] +(let [host "0.0.0.0"] (tcp-server {:host host}) (tcp-server {:host host :port 5554 :tls? true - :key "/client.key.pkcs8" - :cert "/client.pem" - :ca-cert "/CA.pem"}) + :key "/client.key.pkcs8" + :cert "/client.pem" + :ca-cert "/CA.pem"}) (udp-server {:host host}) (ws-server {:host host})) @@ -216,13 +249,13 @@ Usage ; Log expired events. (expired - (fn [event] (info "expired" event)))))) + (fn [event] (info "expired" event)))))) Metrics exposed Metrics provided Scaphandre are documented here. There is only one exception about process_power_consumption_microwatts each process has a service name process_power_consumption_microwatts_pid_exe. As an example, process consumption can be retrieved using the following Riemann query: -(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") +(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre")
; -*- mode: clojure; -*- ; vim: filetype=clojure -(logging/init {:file "riemann.log"}) +(logging/init {:file "riemann.log"}) ; Listen on the local interface over TCP (5555), UDP (5555), TLS/TCP (5554) and websockets ; (5556) -(let [host "0.0.0.0"] +(let [host "0.0.0.0"] (tcp-server {:host host}) (tcp-server {:host host :port 5554 :tls? true - :key "/client.key.pkcs8" - :cert "/client.pem" - :ca-cert "/CA.pem"}) + :key "/client.key.pkcs8" + :cert "/client.pem" + :ca-cert "/CA.pem"}) (udp-server {:host host}) (ws-server {:host host})) @@ -216,13 +249,13 @@ Usage ; Log expired events. (expired - (fn [event] (info "expired" event)))))) + (fn [event] (info "expired" event))))))
(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre") +(service =~ "process_power_consumption_microwatts_%_firefox") or (service =~ "process_power_consumption_microwatts_%_scaphandre")
Write the metrics to the terminal Usage: scaphandre stdout [OPTIONS] @@ -185,11 +218,11 @@ Usage - + - - + + @@ -199,17 +232,38 @@ Usage - + - - + +
scaphandre warp10 @@ -150,7 +183,7 @@ Usage You need a token to be able to push data to a warp10 instance. The SCAPH_WARP10_WRITE_TOKEN env var can be used to make it available to scaphandre. Please refer to the warp10 documentation to know how to get the token in the first place. -As always exporter's options can be displayed with -h: +As always exporter’s options can be displayed with -h: Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -158,27 +191,27 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help With default options values, the metrics are sent to http://localhost:8080 every 60 seconds -Use -q or --qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. +Use -q or –qemu option if you are running scaphandre on a hypervisor. In that case a label with the vm name will be added to all qemu-system* processes. This will allow to easily create charts consumption for each vm and defined which one is the top contributor. -Metrics provided Scaphandre are documented here. +Metrics provided Scaphandre are documented here.
Expose the metrics to a Warp10 host, through HTTP Usage: scaphandre warpten [OPTIONS] @@ -158,27 +191,27 @@ Usage Options: -H, --host <HOST> FQDN or IP address of the Warp10 instance [default: localhost] -p, --port <PORT> TCP port of the Warp10 instance [default: 8080] - -S, --scheme <SCHEME> "http" or "https" [default: http] + -S, --scheme <SCHEME> "http" or "https" [default: http] -t, --write-token <WRITE_TOKEN> Auth token to write data to Warp10. If not specified, you must set the env variable SCAPH_WARP10_WRITE_TOKEN -s, --step <SECONDS> Interval between two measurements, in seconds [default: 2] -q, --qemu Apply labels to metrics of processes looking like a Qemu/KVM virtual machine -h, --help Print help
With Stdout exporter, you can see all metrics available on your machine with flag --raw-metrics. @@ -147,13 +180,13 @@
